A fully approved search and rescue transponder that complies with IMO SOLAS regulations and boasts a superior lithium battery that provides over 96 hours of operating life in standby mode, and 12 hours in active operating life. The compact unit is supplied with a sleek wall mount that ensures it can be kept out of the way, yet still readily accessible in the event of an emergency. When interrogated by radar, ACR Pathfinder PRO returns 12 intense blips back to the vessels radar screen, greatly enhancing search and rescue efforts.
Key Features:
96 hour operational life in stand-by mode.
Complies with IMO, MED, FCC and IEC standards.
Enhances radar returns with 12 intense blips, whereby the first blip represents the SARTs location.
Transmits through the 9.2-9.5 GHz band marine radar when interrogated by radar
Vessel mounting bracket and collapsible pole
Compact unit (227 x 65mm) easily packs into life raft.
Waterproof to 10 meters (33 ft).
Specifications:
Size: 8.94 x 2.56 x 2.36” (227 x 65 x 60 mm).
Weight: 440g.
Deployment: Manual.
Operation: Break protective cover, slide and hold yellow switch to the left, slide the red switch into the down position.
Battery: Lithium/Iron Disulfide (Li/FeS2) Non-Hazardous (5-year replacement life).
Waterproof: > 10 meters (33 ft) @ +20°C.
Certification: FCC, MED, Industry Canada, and Chinese CCS type approval certificate. Tested to IMO and IEC Standards.
Frequency: 9.2-9.5GHz.
Output Power (EIRP): >26 dBm eirp.
Temperature Range (operating): -20°C to +55°C.
Temperature Range (storage): -30°C to +70°C.
Operating Life (Standby): > 96 Hours
Operating Life (Active): > 12 Hours.
Limited Warranty: 2 years.
